The HT0999 optical-electrical slip ring is a hybrid rotating connector designed to transmit optical signals together with electrical signals or power during continuous 360° rotation. It enables stable transmission between stationary and rotating parts, making it suitable for applications requiring high-speed data, large information capacity, high precision, and long-distance transmission.
The fiber optic section supports single-mode or multimode fiber transmission, with operating wavelengths including 1310/1550nm and 850/1310nm. Compared with traditional electrical transmission, optical signal transmission is non-contact, low-loss, and free from electromagnetic interference, helping improve signal stability and service life.
This model can be used in systems requiring both optical communication and electrical transmission, such as robots, material handling systems, medical systems, radar systems, video surveillance systems, offshore equipment, naval systems, and other complex rotating equipment.
| Item | Specification |
|---|---|
| Product Type | Optical-Electrical Slip Ring |
| Fiber Type | Single-mode (SM), Multimode (MM) |
| Operating Wavelength | 1310/1550nm, 850/1310nm |
| Insertion Loss | <4dB |
| Insertion Loss Fluctuation | <1dB |
| Return Loss | ≥35dB |
| Working Temperature | -40°C to +85°C |
| Storage Temperature | -50°C to +85°C |
| Protection Rating | IP54 / IP65 / IP67 optional |
| Rated Speed | 0–300RPM |
| Estimated Lifespan | >100 million cycles |
| Sheath Type | TPU or armored optional |
| Connector Type | FC / LC / SC / ST, PC/APC end face optional |
| Transmission Type | Optical signal + electrical signal / power hybrid transmission |
To select a suitable optical-electrical slip ring, please confirm the following information:
Fiber type
Number of fiber channels
Operating wavelength
Insertion loss requirement
Return loss requirement
Electrical circuit number
Current and voltage requirements
Signal type or power transmission requirement
Rated speed
Working temperature
Protection grade
Cable sheath type
Connector type and end face type
Cable length
Installation space and structure
Whether optical, electrical, power, signal, or other hybrid transmission is required
If you are not sure which model is suitable, please send us your equipment requirements. Our engineers can help recommend a suitable optical-electrical slip ring solution.
Combines fiber optic transmission with electrical signal or power transmission
Supports single-mode and multimode fiber options
Suitable for continuous 360° rotation
Supports high-speed and long-distance optical signal transmission
Low insertion loss, stable optical performance
Return loss ≥35dB
Optical transmission is not affected by electromagnetic interference
Optional protection grades include IP54, IP65, and IP67
TPU or armored sheath options available
FC, LC, SC, and ST connector options available
PC/APC end face options available
Estimated lifespan over 100 million cycles
Compact structure, suitable for integration into complex rotating equipment
Can be customized according to optical, electrical, signal, power, and installation requirements
| Application | Typical Use |
|---|---|
| Robots | Optical and electrical signal transmission in rotating robotic systems |
| Material Handling Systems | Stable hybrid transmission in rotating handling equipment |
| Medical Systems | High-speed signal transmission in precision rotating medical equipment |
| Remote Control Systems | Optical communication and signal transfer in control systems |
| Radar Systems | High-speed optical signal transmission in rotating radar equipment |
| Rotating Turrets on Vehicles | Hybrid transmission in vehicle-mounted rotating systems |
| Video Surveillance Systems | Stable video, data, and signal transmission in rotating monitoring systems |
| Offshore Equipment | Reliable transmission in marine and offshore rotating environments |
| Naval Systems | Optical-electrical transmission in shipborne rotating systems |
| National or International Security Systems | Signal and data transmission in security-related rotating equipment |
| Submarine Operations Systems | Optical communication in underwater or subsea rotating systems |
Fiber type
Single-mode or multimode fiber
Number of fiber channels
Operating wavelength
Insertion loss requirement
Return loss requirement
Electrical circuit number
Current capacity
Voltage rating
Signal type
Power circuit integration
Communication signal integration
Cable length
Connector type
PC/APC end face
Sheath type
TPU or armored cable
Protection grade
Rated speed
Working temperature range
Storage temperature range
Housing structure
Installation structure
Integration with electrical signal, power, data, or other hybrid transmission requirements
If the standard model does not meet your requirements, please send us your application details, including fiber type, fiber channel number, wavelength, insertion loss requirement, electrical circuit number, current, voltage, signal type, rated speed, connector type, cable length, protection grade, installation space, and working environment.
Our engineers can help confirm the suitable model or provide a customized optical-electrical slip ring solution according to your equipment requirements.
